| Place of Origin: | Guangdong, China |
| Brand Name: | SIXWGH |
| Attribute Name | Attribute Value |
|---|---|
| Brand Name | (Your Brand Here) |
| Model Number | ZB-REPEATER-01 |
| Product Type | Zigbee Signal Repeater / Range Extender |
| Wireless Protocol | Zigbee 3.0 (Must be used with a Zigbee Gateway) |
| Compatible Platform | Exclusively for Tuya Smart / Smart Life App Ecosystem |
| Signal Extension Range | Effective range extension of 20-30 meters per repeater |
| Max Outdoor Range | >300 meters (Line of Sight, Open Area) |
| RF Power | +21dBm |
| Power Supply | DC 5V/1A via Micro-USB port (USB cable included, adapter not included) |
| Product Dimensions | 61.5mm x 28mm x 14mm (Ultra Compact) |
| Operating Temperature | -10°C ~ 55°C |
| Indicator Light | LED for status display (Pairing/Working) |
| Reset Button | For device reset and re-pairing |
| Primary Function | Expands Zigbee network coverage, strengthens signal, eliminates dead zones |
| Application | Large homes, villas, offices, warehouses, hotels with Tuya Zigbee systems |
Q1: What is this device, and what does it do?
A: This is a Zigbee Signal Repeater (Range Extender). Its sole purpose is to receive and re-transmit Zigbee signals, effectively extending the coverage range of your existing Tuya or Smart Life Zigbee gateway by 20-30 meters. It helps eliminate "dead zones" where your Zigbee devices (sensors, switches) have weak or no signal.
Q2: Can I use this repeater by itself, without a Zigbee gateway?
A: No, you cannot. This is a critical point. This repeater is an accessory for a Zigbee network. You must already have a Tuya/Smart Life compatible Zigbee gateway (e.g., Tuya Zigbee Hub) to create the main network. This repeater then connects to that network to extend it.
Q3: How do I install and set it up?
A: It's very simple (Plug-and-Play):
Plug the repeater into any USB power source (wall charger, TV USB port, etc.) within the existing but weak range of your Zigbee gateway.
Open your Tuya/Smart Life app.
The app should automatically detect the new device (or you may need to add it as a "Zigbee Repeater" from the device list). Follow the in-app pairing instructions.
Once paired, you can move other distant Zigbee devices closer to it for a better connection.
Q4: How much area can one repeater cover? How many do I need?
A: One repeater can effectively extend the signal 20-30 meters in indoor environments (through walls). For a very large house or multi-story building, you may need multiple repeaters. They form a "mesh" network, where data can hop from one repeater to another, allowing you to cover vast areas.
Q5: Is it compatible with Amazon Alexa or Google Home?
A: Indirectly, yes. Since it works within the Tuya/Smart Life ecosystem, and that ecosystem can be linked to Alexa/Google, any Zigbee device that connects through this strengthened network will be available for voice control via Alexa/Google, as long as your gateway supports that integration.
Q6: Is it compatible with other Zigbee systems like Samsung SmartThings, Philips Hue, or Aqara?
A: No. This repeater is designed exclusively for the Tuya and Smart Life app ecosystem. It uses Tuya's specific Zigbee stack and will not work with other proprietary Zigbee systems like SmartThings, Hue, or Aqara (unless they use a Tuya gateway).
Q7: Can I use it outdoors?
A: The product parameters list an outdoor range of >300m, suggesting it has a strong signal. However, the device itself is not rated as waterproof (IP rated). For outdoor use, it must be placed in a completely dry and sheltered location, such as under a roof eave or in a waterproof electrical box.
Q8: Do you offer OEM/ODM services for this repeater?
A: Yes, we do. For bulk orders from distributors, smart home solution providers, or real estate developers, we can customize the product with your logo, packaging, and potentially adjust firmware for specific projects. Please contact us for details.
